What Benefits Does a PSA Nitrogen Generator Bring to the Red Wine Industry?

2025-11-07 | More News

PSA (Pressure Swing Adsorption) nitrogen generators are devices that produce nitrogen by separating it from air based on the principle of selective adsorption. They typically consist of adsorption towers, an air compressor, a control system, and carbon molecular sieves. The working principle involves cyclic processes of pressurized adsorption and depressurized regeneration: during pressurization, carbon molecular sieves selectively adsorb oxygen, allowing nitrogen to be collected; during depressurization, the sieves regenerate. These generators are known for their simple process flow, high automation, fast nitrogen production, and low operating costs, and are widely used in industries such as food, pharmaceuticals, and chemicals.
During the production of red wine, it is inevitable to come into contact with air, which leads to wine oxidation and affects the quality of finished red wine.
Filling with nitrogen can effectively prevent red wine from reacting with oxygen in the air, extend the shelf life of red wine, reduce the possibility of spoilage, and better preserve the original flavor of red wine. Nitrogen is widely available and abundant. Compared with other inert gases, it is more economical. Therefore, nitrogen generators have gradually become an indispensable equipment in red wine processing, being economical and safe.
Specifically, nitrogen can be involved in the following production and processing links:
  • Purging and Flushing: Nitrogen can be used to purge and flush wine pipelines, and pre-fill nitrogen before red wine filling.
  • Nitrogen Blanketing: Fill nitrogen into containers that are not fully filled to expel air and achieve nitrogen blanketing.
  • Red Wine Transportation: When red wine flows between different containers, it is necessary to inject nitrogen to expel air in the pipeline to achieve sealing. At the same time, perform bubble removal on red wine to eliminate excess oxygen.
  • Bottling: When filling red wine, nitrogen is filled into the container before and after filling to seal the container and isolate air from contact with red wine.
As the competition in the red wine industry becomes increasingly fierce, it is believed that PSA nitrogen generators will gradually become an indispensable part of the red wine production line.

In addition to psa nitrogen generator, we also produce VPSA Oxygen Generators,PSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in psa nitrogen Systems or other products, please feel free to send an email to [email protected]. We will be very happy to serve you.

Nitrogen production (Nm³/h) Effective air consumption (Nm³/min) Inlet pipe size (DNmm) Outlet pipe diameter (DNmm) Host L×W(mm)
5 0.7 25 15 1150×600
10 1.4 25 15 1250×880
20 2.8 40 15 1750×1000
30 4.2 40 25 2150×1100
40 5.6 50 25 2250×1140
50 7.0 50 25 2500×1150
60 8.4 50 25 2750×1450
80 11.2 65 32 2750×1450
100 14.0 65 32 2850×1550
200 28.0 65 32 3250×1820
300 42.0 80 40 3500×2150
